VARIOUS WASHERS FOR STEEL & PLASTIC DRUM CLOSURES

Washers also named Gaskets .Qiming Packaging Rubber Washers And Seals Washers  With Good-sealing ,Acid-proof,Alkali-proof,Oil-proof,Heat-resistant,.Gaskets For 2 ” Flanges & Plugs , 3/4″ Flanges &Plugs .

Material: PE, EDPM( FDA Compliant),BUNA. Black & White Available. Please Click  Steel Drum Plugs,Drum Flanges,Plastic Plugs,Nylon Plugs  To See Their Applications.

GASKET RING WASHER RING DRAWING

GASKETS RING WASHERS RING DRAWING

Qiming Gasket Ring Washer Technical Data
Item Inner Dia Rectangular Ring O Ring
d δ b d1
G2 Gasket 50.5±0.5 2.6±0.2 2.7±0.2 3.0±0.2
G3/4 Gasket 20.0±0.5 2.6±0.2 2.7±0.2 3.0±0.2
G2 Gasket 60.5±0.5 2.7±0.2 3.2±0.2 3.3±0.2
G3/4 Gasket 27.5±0.5 2.7±0.2 2.4±0.2 3.3±0.2
All the unit in millimetre (mm)-Free Samples available for quality checking
White  PE Gaskets --Qiming Packaging

White  PE Washers –Qiming Packaging

White PE Washers From Qiming Packaging Specification

  • Application

    Poly Ethylene(PE)Gaskets

    for 2 inch and 3/4 inch steel drum closures and plastic drum plugs

  • Size

    2 inch and 3/4 inch or so

  • Feature

    Good-sealing ,Acid-proof,Alkali-proof,Oil-proof, limited Heat-resistant.

  • Shape

    O ring with round or square crosss section

  • Material

    New Poly Ethylene(PE)

  • Color

    Translucent white

  • Package

    Plastic bag/carton box

  • Delivery

    5 days as usual or as per your quantity.
